Air introduction - Settling Chamber

CAM E/I_IM
From 2600 m3/h to 5000 m3/h

The system of air INTRODUCTION with “Settling Chamber” has the characteristic of guaranteeing continuous air changes with the primary objective of transferring the heat generated by the equipment to the external environment (for dissipation).
This happens thanks to the combined operation of a fan positioned inside the Settling Chamber and the filtering sections.
The Settling Chamber can be installed externally or internally, in according with the typology of the installed air conditioners and with the space available inside the local.

SYSTEM KIT WITH SETTLING CHAMBER
• INTERNAL Settling Chamber + fan + air filters + external door / EXTERNAL Settling Chamber + fan + air filters + air introduction grid
• Electrical panel “Command and Control” consists of general disconnecting switch breaker, PLC, maximum temperature thermostat
• External air extraction plenum
• Overpressure damper
• Internal plenum grid (optional)

The system is designed to be managed by its own PLC to manage the operation cycle and detect the possible causes of alarm. This system when coupled with an Ethra Tech air conditioner can be managed by the same air conditioner controller, without need for a dedicated PLC.
Fan speed is adjusted with “PROPORTIONAL” (0-10V) signal. By adopting the regulation “PROPORTIONAL”, are avoided thermal shock conditions when the outside temperature is very low. This system can also be identified as an emergency system to cool the room as it is provided an electromechanical controller (thermostat) that allows to feed the fan in an independently and separately when the detected temperature exceeds the predetermined values.

Technical features
• External panels painted with epoxide powders
• Very light weight
• Easy operations for installation
• Easy access for service and maintenance
• Low noise levels
